Electrical Junction Connector Terminal Thread Strips

8 Pole Unipolar Terminal Block Made with high-quality polyamide66 materials, it features good insulation and fire- resistance,heat-resistance making it ideal for various industrial and ensures secure and efficient connections.    ItemNo  MJTB012-01-05  Contact Material  Brass  Termination Method  Screw Down  Working Temperature  -30℃ - 110℃  Material  Polyamide66  Inserts  Brass  Housing  Polyamide66(PA66)  Screws  Brass

10 Poles Connector Unipolar Terminal Blocks  Constructed from premium polyamide66 materials, offers superior insulation, fire resistance, and heat resistance. These qualities make it an ideal choice for various industrial applications, ensuring secure and efficient electrical connections.    ItemNo  MJTB012-20-24  Contact Material  Brass  Termination Method  Screw Down  Working Temperature  -30℃ - 110℃  Material  Polyamide66  Inserts  Brass  Housing  Polyamide66(PA66)  Screws  Brass

Junction Connectors Terminal Thread Block are designed for connecting one or multiple conductors without cutting the main cable. These terminal strips feature an outer shell made of PA66, known for its durability and insulation properties. The conductors and screws are made of brass, with the screws brass-plated to enhance corrosion resistance and conductivity.    ItemNo  MJTB026  Contact Material  Brass  Termination Method  Screw Down  Working Temperature  -40℃ - 110℃  Material  Polyamide66  Inserts  Brass  Housing  Polyamide66(PA66)  Screws  Brass，Brass Plated

Circuit Breaker Accessories Insulated Copper Busbar is an advanced solution designed to enhance power distribution efficiency and safety across a wide range of applications. Built with high-quality copper, this busbar combines durability with exceptional performance, making it an ideal choice for both simple and complex electrical systems.    ItemNo  MJTB102T  Material  Copper,PVC  Color  Grey

Pluggable male-femal Teminal Strips from high-quality materials such as natural PA6, these terminal strips ensure durability and reliable performance.  they meet stringent safety standards.  The terminal strips are available with or without wire protection, and they can be easily cut to size or supplied cut to length upon request.Featuring closed inserts (middle barrier) options and captive terminal screws, these terminal strips are perfect for secure and efficient connections.    ItemNo  MJTB011-01-04  Contact Material  Brass  Termination Method  Screw Down  Glow Wire Test  850 ℃  Material  Polyamide6  Number of Ways  12  Inserts  Brass  Housing  Polyamide6(PA6)  Screws  Steel,Zinc plated

H Type PE Electrical Choc Terminal Strip Crafted with heat-resistant polythene insulation, these terminal blocks withstand up to 65°C. Each terminal block features 24 connection screws, simplifying wiring setups for various projects. the terminal strip are ideal for various basic electrical installation tasks.This terminal block has the advantages of being lightweight and rigid, with resistance to corrosion and high tensile strength. It also features raised screw down terminals for ease of wiring.      ItemNo  MJTB001-01-09  Contact Material  Brass  Termination Method  Screw Down  Working Temperature  -40℃ - 65℃  Material  Polyethylene Housing  Number of Ways  12  Inserts  Brass  Housing  Polyethylene (PE)  Screws  Steel,Zinc plated

 Din Rail Earthing Connection Busbar Terminal Block  is engineered to deliver a dependable and secure solution for wire connections. Each terminal is insulated from the adjacent ones, ensuring organized circuits and preventing any potential short circuits.    ItemNo  MJTB031  Contact Material  Brass  Termination Method  Screw Down  Material  Polyamide or Polyethylene Housing  Inserts  Brass  Housing  Polyamide (PA),Polyethylene(PE)  Screws  Steel,Zinc plated

 Wire Protection Brass With Stainless Spring Terminal Strip shares many similarities in body and clamp design with others on the market. However, its standout feature lies in the integration of a steel plate within the clamp mechanism. This innovative design ensures that when tightening the conductor screw, the pressure is evenly distributed and does not compromise the integrity of the conductor's structure.    ItemNo  MJTB002-01-05  Contact Material  Brass(Nickled) With Stainless Spring  Termination Method  Screw Down  Glow Wire Test  850 ℃  Material  Polypropylene Housing  Number of Ways  12  Inserts  Brass  Housing  Polypropylene (PP)  Screws  Steel,Zinc plated
